Description

The photo shows a real-life example of a Modern Expo shelving unit with baskets in a store, for which we selected and installed shelving and retail equipment. More examples in the Shelving Gallery: universal metal wall-mounted shelving with baskets. Mesh wire baskets painted white. Standard color finish is RAL 9001. Other colors are available upon request. Baskets can be coated with white powder paint or have a zinc coating. Baskets can have any number of compartments. Universal shelving with 25 mm perforated uprights; universal shelving allows increasing the product display by 25%. The load-bearing elements of the shelving are made of profile tubes 80*30 mm with a wall thickness of 2.5 mm. Shelves and shelving walls are made of cold-rolled coil steel, 0.6 mm thick, with reinforced shelves made of steel, 0.8 mm thick. Brackets are made of sheet metal, 3 mm thick. All metal elements are coated with Austrian-produced powder paint. All shelves are equipped with wire barriers, 56 mm in height. Standard paint color is light cream RAL 9001 gloss. Maximum permissible load on the shelving without screwing to the wall is 500 kg (excluding the load on the bottom shelf). Dynamic loads on the shelving shelf are not provided for. The product must be evenly distributed over the entire shelf area. The weight of the product must decrease with height. The shelving units are equipped with adjustable legs capable of compensating for floor unevenness up to 30-35 mm.
